rotowash
Rx redesign
SPARE PARTS - ERSATZTEILE
Dokument - document: #72370
Version: 09.01.09
Seite - Page: 2 von 3
Erstellt von - Made by: van Ooijen
1
Housing unit E R20 11 tooth saffron yellow cpl.
1
Housing unit E R30 11 tooth saffron yellow cpl.
1
Housing unit E R45-60 11 tooth saffron yellow cpl.
1.1
Clamp strip
1.2
Clamp bracket
1.3
Lockwasher M4 A2
1.4
Schrew M4x8 A2
1.5
Ballbearing 6003 2RS
1.6
Flange SW10
1.7
Compressing spring 5x0,6x30
1.8
Adjuster slide
1.9
Clampdisc KS4
1.10
Pilot segment
1.11
Bumper
1.12
Snapring A17 16x1
1.13
Distance ring
1.14
V-Ring
1.15
O-Ring 41,00 x 1,78
1.16
Protective plate
1.17
Screw M3x5
2
Housing unit E R20 11 tooth saffron yellow cpl.
2
Housing unit L R30 11 tooth saffron yellow cpl.
2
Housing unit L R45-60 11 tooth saffron yellow cpl.
1470Y01
1469Y01
1314Y01
182K01 *
279K03 *
188N01 *
384N01
1F14703 *
205K01 *
126T01 *
131E01 *
114N01 *
136N01 *
195N01 *
168N01 *
Part. No.
1316Y01
1472Y01
1471Y01
347N02 *
Description:
361K01 *
347K01
218N01 *
206N01 *
ITEM No
