rotowash
Rx redesign
SPARE PARTS - ERSATZTEILE
Dokument - document: #72639
Version: 20.01.09
Seite - Page: 2 von 2
Erstellt von - Made by: van Ooijen
ITEM No
1
Tank cpl. for Stickhandle
1.1
Tube 8x6 mm 37 cm cpl.
1.2
Quick fit Valve
1.3
Tank cover
2
Stick handle for tank cpl.
2.1
Stickhandle lower part cpl.
2.2
Stickhandle upper part cpl.
2.3
Cable safety (Easy mounting)
2.4
Bowden control cpl.
3
Loop handle R30-60 B cpl.
3.1
Cable HO5VVF for Australia
3.1
Cable SJT 3x16 AWG 110 Volt for UK, Japan, Taiwan, Korea
3.2
Tank B black cpl
3.3
Protectionlid with plate
3.4
Thermorelay 5 A witch schwitch red
3.4
Thermorelay 10 A 110Vwitch schwitch green
4
Loop handle R30-60 S cpl.
4.1
Bowdencontrol for loop handle cpl. x
4.2
WaterTank S cpl
* = This part is also used by R2 - R5 machines.
344K02
Part. No.
1285Y01
1360Y01
232K01 *
1361Y01
Description:
343K01
336E01
121E02 *
on request
158Y04 *
294K01
156Y05 *
1410Y01 *
1431Y01 *
412Y03 *
on request
1421Y01
123E01 *
334E01
